ST953H Wheel Loader
Hydraulic wheel loader with diesel engine for heavy-duty material handling operations
- Rated load
5000kg - Rated bucket capacity
2.8m³ - Max. dumping height
3040±15mm - Dumping reach
1290mm
Specifications
| Rated load | 5000kg |
| Rated bucket capacity | 2.8m³ |
| Max. dumping height | 3040±15mm |
| Dumping reach | 1290mm |
| Overall length (bucket on the ground) | 7380mm |
| Overall width | 2840mm |
| Bucket width | 3020mm |
| Height (to the top of cabin) | 3340mm |
| Wheelbase | 2760mm |
| Track width | 2240mm |
| Min. ground clearance | 450mm |
| Operating weight | ≤16500kg |
| Max. breakout force | 140kn |
| Gradeability | 28° |
| Turning angle | 35±1° |
| Turning radius | 6180mm |
| Dump angle at any position | 45° |
| Dump angle at any position | 45° |
| Lifting time of bucket | ≤5.8s |
| Total hydraulic cycle time | ≤12s |
| 1st gear forward | 11.5km/h |
| 2nd gear forward | 38km/h |
| 1st gear reverse | 16km/h |
| Engine model | Weichai Strye WD10G220E23 |
| Engine type | In-line, water cooled, four-stroke direct injection |
| Rated power | 162kW |
| Cylinder | 6-126×130mm |
| Rated speed | 2000rpm |
| Torque converter model | YJSW315-6 |
| Torque converter type | Single stage, double turbine, colligation |
| Transmission model | ZL40/50 |
| Transmission type | Power shift, planetary |
| Number of speeds | Forward 2, Reverse 1 |
| Tire | 23.5-25-20PPR |
Note:
With ongoing technological advancements, product specifications and configurations are subject to change without prior notice. In case of any uncertainty, the final confirmation provided by our international trade sales team shall prevail.
Features
- Single-stage, four-element (dual-turbine) torque converter enables continuously variable transmission, providing smooth starts and easy control
- Power shift transmission combined with a hydraulic implement system ensures effortless operation and precise handling
- Z-bar loader linkage delivers strong breakout force and high dumping height, maximizing productivity in loading and lifting tasks
- All-wheel dual-line disc-caliper braking system, supported by rear-mounted air reservoirs, guarantees safety, stability, and reliable braking performance in demanding conditions
Which wheel loader is suitable for compact workspaces and environmentally sensitive areas?
Which wheel loader is suitable for compact workspaces and environmentally sensitive areas?
The electric front-end wheel loader is ideal for confined sites. With a compact body, narrow width, and small turning radius, it uses a pure electric drive system powered by a high-performance lithium battery. It delivers zero emissions and quiet operation, making it suitable for urban projects, factories, and agricultural areas with strict environmental standards.
Which model is recommended for large-scale mining operations requiring higher bucket capacity and wider dumping reach?
Which model is recommended for large-scale mining operations requiring higher bucket capacity and wider dumping reach?
The diesel front-end wheel loader is designed for heavy-duty applications. It features a 3 m³ bucket capacity and a maximum dumping height of 3,300 mm, providing excellent material handling efficiency and adaptability for intensive mining and loading operations.
Which wheel loader is suitable for forestry operations that require strong grip and stable performance when handling logs?
Which wheel loader is suitable for forestry operations that require strong grip and stable performance when handling logs?
The log handling diesel wheel loader is equipped with an extended grapple arm specifically designed for large-diameter timber. It ensures firm gripping and efficient transfer of logs. The combination of a fixed-shaft Beilian gearbox and a Shantui torque converter provides easy maintenance, smooth power transmission, and superior overload resistance.
Can the stone-handling diesel wheel loader operate effectively on rough or uneven terrain?
Can the stone-handling diesel wheel loader operate effectively on rough or uneven terrain?
The block handling diesel wheel loader features four-wheel drive and strong traction, combined with high ground clearance to handle challenging site conditions. Its large counterweight offset angle enhances climbing ability, while a maximum lifting capacity of 16 tons, long wheelbase, and reinforced frame ensure operational stability. The maximum unloading height of 3,450 mm allows efficient loading and dumping on uneven surfaces.
